Core Technical Advantages

✅ High Hardness & Wear Resistance – HRA90+ hardness, 5–8× longer service life vs. metal probes

✅ Insulation & Non-Magnetic – No electromagnetic interference, ideal for high-frequency and sensitive testing scenarios

✅ Ultra-Precision Tip Machining – ±0.002mm tip accuracy, ensuring stable contact and low contact resistance

✅ Cleanroom Compliance – Smooth, pore-free surface, no particle contamination

✅ Chemical & Thermal Stability – Resists corrosion and thermal shock, maintaining performance in harsh test conditions

Key Applications

• Semiconductor Testing: Wafer probe cards, IC package testing, die sorting probes
• Electronic Component Testing:PCB/FPC continuity testing, impedance measurement probes
• Optical Instrumentation:Lens positioning probes, laser alignment detection
• Precision Machinery: Coordinate measuring machine (CMM) probes, automated positioning sensors

Technical Support & Services

✅ Custom Design & Machining – Tailored tip geometry, length, and mounting interfaces to meet equipment specifications

✅ Material Selection – Y-TZP, alumina, and high-purity ceramic formulations

✅ Surface Treatment – Precision lapping, anti-static coatings, and passivation

✅ Quality Assurance – CMM inspection reports, tip sharpness testing, and cleanroom certification
